ECO- FRIENDLY AND DURABLE FLEXIBLE LED STRIP LIGHT

RGB flexible led strips are becoming the in thing, and SDIP has mastered the skill of being able to combine the beauty of multiple colors and bendable led strips. SDIP flexible led strip saves up about 80% of the energy, making it more efficient than conventional lighting. SDIP bendable led strips and flexible RGB led strip lights are durable, lasting longer than regular lightings. At SDIP we ensure quality assurance in the manufacturing, packaging, and distribution of our flexible led strip lights. Making us the most sort after flexible light strip manufacturers. Our flexible light strips convert about 95% of energy into light and only about 5% is lost as heat. Thus SDIP flexible led strip provides businesses, homes, and offices with a cost-effective source of lighting while offering radiant varieties of colors to spice up your surroundings and spaces.

Outside manufacturing and distribution of bendable led strips, SDIP provides other services such as project implementation and installation of our flexible light strips. SDIP provides services such as debugging, site overview, and on-site professional expertise to ensure safe and quality installation of our SMD (surface mounted diode) led flexible strips.

SDIP offers shipments of our SMD led flexible strips to your desired location worldwide. Send us an email today!

SMD LED Flexible Strips

RGB Flexible LED Strip

Flexible Light Strip

Flexible LED Strip

Flexible LED Strip Lights

Bendable Flexible LED Strip

Super Blendable and Super Dependable SMD LED Flexible Strips



SDIP manufactured SMD led flexible strips to provide a versatile flexible led strip that not only adapts easily but bends to any fitting surfaces including circular, and curved surfaces. Our flexible led strip lights can even make acute bends as low as a 90˚ bend downwards without the loss of its vibrant colors. SDIP manufactured flexible led strip light maintains its radiance, brightness and navigates bends without pixelation.

With SDIP RGB flexible led strip you are ensured of a lighting source for your buildings, offices, and homes that lightens up those intricate corners providing the best possible detailing without stress or doubt.

Send us an email today and we will send you a free quote on our product manufacturing and delivery globally.

Model SDIP-F12V-10L-30LED-W-WS2811 SDIP-F12V-16L-48LED-W-WS2811 SDIP-F12V-20L-60LED-W-WS2811
Voltage: DC12V DC12V DC12V
Current: 0.06A/LED 0.06A/LED 0.06A/LED
Max Power: 7.2w/m 11.52w/m 14.4w/m
IC Type: External External External
IC: WS2811 WS2811 WS2811
IC Quantity: 10 IC/meter 16 IC/meter 20 IC/meter
LED Type: SMD5050 SMD5050 SMD5050
LED Quantity: 30 LEDs/meter 48 LEDs/meter 60 LEDs/meter
LED Color: RGB RGB RGB
LED Interval: 33.3mm 20.8mm 16.6mm
Cut Size: 3LED 3LED 3LED
LED Lifespan: 50,000hrs 50,000hrs 50,000hrs
PCB Width: 10mm 10mm 10mm
FPCB Thickness: 3A copper 3A copper 3A copper
PCB: Double-sided Flexible PCB Double-sided Flexible PCB Double-sided Flexible PCB
FPCB Color: White/Black White/Black White/Black
Channel Order: RGB RGB RGB
Gray Scale: 256 256 256
IP rate: IP20/IP65/IP67/IP68 IP20/IP65/IP67/IP68 IP20/IP65/IP67/IP68
Working Temp: -40°~ 70° -40°~ 70° -40°~ 70°
Roll length: 5m/Roll 5m/Roll 5m/Roll
Package: Anti-static Aluminum Foil Bag Anti-static Aluminum Foil Bag Anti-static Aluminum Foil Bag

Model  SDIP-F5V-30L-30LED-W-WS2812 SDIP-F5V-60L-60LED-W-WS2812  SDIP-F5V-144L-144LED-W-WS2812
Voltage: DC5V DC5V DC5V
Current: 0.06A/LED 0.06A/LED 0.06A/LED
Max Power: 9w/m 18w/m 43.2w/m
IC Type: Built-in Built-in Built-in
IC: WS2812B WS2812B WS2812B
IC Quantity: 30 IC/meter 60 IC/meter 144 IC/meter
LED Type: SMD5050 SMD5050 SMD5050
LED Quantity: 30 LEDs/meter 60 LEDs/meter 144 LEDs/meter
LED Color: RGB RGB RGB
LED Interval: 33.3mm 16.6mm 16.6mm
Cut Size: 1 x LED 1 x LED 1 x LED
LED Lifespan: 50,000hrs 50,000hrs 50,000hrs
PCB Width: 10mm 10mm 10mm
FPCB Thickness: 3A copper 3A copper 3A copper
PCB: Double-sided Flexible PCB Double-sided Flexible PCB Double-sided Flexible PCB
FPCB Color: White/Black White/Black White/Black
Channel Order: RGB RGB RGB
Gray Scale: 256 256 256
IP rate: IP20/IP65/IP67/IP68 IP20/IP65/IP67/IP68 IP20/IP65/IP67/IP68
Working Temp: -40°~ 70° -40°~ 70° -40°~ 70°
Roll length: 5m/Roll 5m/Roll 5m/Roll
Package: Anti-static Aluminum Foil Bag Anti-static Aluminum Foil Bag Anti-static Aluminum Foil Bag

Model  SDIP-F5V-30L-30LED-W-WS2813​ SDIP-F5V-60L-60LED-W-WS2813 SDIP-F5V-144L-144LED-W-WS2813
Voltage: DC5V DC5V DC5V
Current: 0.06A/LED 0.06A/LED 0.06A/LED
Max Power: 9w/m 18w/m 43.2w/m
IC Type: Built-in Built-in Built-in
IC: WS2813 WS2813 WS2813
IC Quantity: 30 IC/meter 60 IC/meter 144 IC/meter
LED Type: SMD5050 SMD5050 SMD5050
LED Quantity: 30 LEDs/meter 60 LEDs/meter 144 LEDs/meter
LED Color: RGB RGB RGB
LED Interval: 33.3mm 16.6mm 16.6mm
Cut Size: 1 x LED 1 x LED 1 x LED
LED Lifespan: 50,000hrs 50,000hrs 50,000hrs
PCB Width: 10mm 10mm 10mm
FPCB Thickness: 3A copper 3A copper 3A copper
PCB: Double-sided Flexible PCB Double-sided Flexible PCB Double-sided Flexible PCB
FPCB Color: White/Black White/Black White/Black
Channel Order: RGB RGB RGB
Gray Scale: 256 256 256
IP rate: IP20/IP65/IP67/IP68 IP20/IP65/IP67/IP68 IP20/IP65/IP67/IP68
Working Temp: -40°~ 70° -40°~ 70° -40°~ 70°
Roll length: 5m/Roll 5m/Roll 5m/Roll
Package: Anti-static Aluminum Foil Bag Anti-static Aluminum Foil Bag Anti-static Aluminum Foil Bag

Model SDIP-F12V-30L-30LED-W-WS2815 F12V-60L-60LED-W-WS2815
Voltage: DC12V DC12V
Current: 0.013A/LED 0.013A/LED
Max Power: 4.68w/m 9.36w/m
IC Type: Built-in Built-in
IC: WS2815 WS2815
IC Quantity: 30 IC/meter 60 IC/meter
LED Type: SMD5050 SMD5050
LED Quantity: 30 LEDs/meter 60 LEDs/meter
LED Color: RGB RGB
LED Interval: 33.3mm 16.6mm
Cut Size: 1 x LED 1 x LED
LED Lifespan: 50,000hrs 50,000hrs
PCB Width: 10mm 10mm
FPCB Thickness: 3A copper 3A copper
PCB: Double-sided Flexible PCB Double-sided Flexible PCB
FPCB Color: White/Black White/Black
Channel Order: RGB RGB
Gray Scale: 256 256
IP rate: IP20/IP65/IP67/IP68 IP20/IP65/IP67/IP68
Working Temp: -40°~ 70° -40°~ 70°
Roll length: 5m/Roll 5m/Roll
Package: Anti-static Aluminum Foil Bag Anti-static Aluminum Foil Bag

Flexible LED Strip Related Products

Power Supply For Flexible LED Strip

Driver For Flexible LED Strip

Controller For Flexible LED Strip

Where innovative Design Meets SDIP Flexible Light Strip



SDIP flexible light strip offers a unique feature that makes it easier to install our bendable led strips. Its ability to adapt to curves prevents the need to cut or link RGB flexible led strip at corners. SDIP SMD led flexible strips offer a higher lumen and consume a lesser amount of energy. Making it a more powerful and efficient flexible led strip light.

SDIP flexible light strips are designed to serve fully as an indoor and an outdoor lighting option, combining durability and elegance in its design and manufacturing. SDIP RGB led strips are water and dust-resistant. SDIP bendable led strip can be used to design logos, names, and signage for your hotel, business, and events. Giving it an even sparkle all year round.



LED light stripsThe Ultimate FAQ Guide– Flexible LED Strip



Flexible LED strips are one of the forms of LED light strips. There are two types of LED strips, i.e. Rigid and Flexible. Flexible LED strips are easy to cut, bend, and drawn easily to any shape of your choice. Due to this high level of flexibility, these are termed flexible LED strips.

  1. What Is A Flexible LED Strip?
  2. Can SMD-led flexible strips be joined together?
  3. Can I connect two flexible led strips?
  4. How do you connect flexible led strips without soldering?
  5. Can you connect four flexible led strip lights?
  6. How many flexible led strip lights can I connect?
  7. How do you connect two flexible light strips without connectors?
  8. How flexible are “flexible led strip lights”?
  9. Can you bend flexible light strips around corners?
  10. Can I cut the bendable led strip?
  11. How do you connect the RGB flexible led strip?
  12. How to bend your flexible RGB led strip lights laterally?
  13. What does SMD mean for LED lights?
  14. How to bend your flexible LED tapes laterally with clip-on connectors
  15. How do you connect two SMD LED flexible strips to one power source?
  16. How to Select an LED Power Supply?
  17. How to power SMD LED Flexible Strips?
  18. How much power do you need for a flexible LED Strip
  19. Can flexible led strips catch on fire
  20. Can I use SMD-led flexible strips without a controller
  21. Can I control multiple RGB flexible led strips with one remote
  22. How bright should my flexible led strip light be?
  23. How do I install my flexible light strip?
  24. What strip is the right colour for me?
  25. How much will a flexible light strip cost?
  26. How to Connect a Flexible light strip?
  27. What transformer do I need for the flexible light strip?
  28. Can I leave a bendable led strip on all night?
  29. Can a bendable led strip give you cancer?
  30. How many amps do I need for the RGB flexible led strip?
  31. How do you stick flexible RGB led strip lights to TV?
  32. HOW LONG CAN flexible RGB LED strip lights to stay on?
  33. What flexible RGB led strip lights are the best?
  34. What wire do you use for SMD-led flexible strips?
  35. How do you connect flexible led strip lights to mains?
  36. Where should a flexible led strip be placed in a room?
  37. How do you connect flexible led strip light to a 12V battery?
  38. Can I power a 12V flexible led strip light with USB?
  39. Factors to Consider When Clipping and Soldering a Flexible light strip?
  40. What is the difference between flexible led strip light and led rigid strip light
  41. How many lumens per led chip do you use for your flexible strip lights?
  42. How to choose the right Flexible LED strip?



1.  What Is A Flexible LED Strip?

These LED Strips are easy to connect, bend, and cut; therefore, they have flexible LED strips.

These strips have a high level of system efficiency.

They can easily follow the plug-and-socket principle. Therefore they are called flexible LED Strips.

These strips are flexible to the extent that you can easily bend them.

These Flexible LED strips can also be cut down and turned into any shape of your choice.

This flexibility of cutting and bending has made called a flexible led strip.

Due to their flexibility properties, these strips are being used in a variety of lighting solutions.



Flexible LED StripFlexible LED Strip



2.  Can SMD-led flexible strips be joined together?

Yes. SMD-LED Flexible strips can be joined together easily.

These SMD-LED strips can be joined together easily with the help of a connecting clip.

A male-to-male connecting clip can be used to join these strips together.

There are few cases When you are not able to Join SMD-LED strips through the clip.

In this case, you will be joining them with the help of a solder.

To perform clipping or soldering, you should keep in mind that you have to cut the wires of LED strips from the copper connections found every two inches in the LED tapes.

Joining SMD LED stripsJoining SMD LED Strips



3.  Can I connect two flexible led strips?

Yes. You can easily connect two flexible LED strips.

It has been told that no more than two strips should be connected.

There is also the possibility of connecting more than two flexible LED strips, but you will need a separate power bus for this purpose.

These power buses should have higher gauge wire to run those two connected strips.

For a single low power source, only two LED strips can be connected. But if the power source is strong enough, we can connect more than two flexible LED strips.

4.  How do you connect flexible led strips without soldering?

This video will help you in knowing about tricks and methods for connecting Flexible LED strips without soldering :



5.  Can you connect four flexible led strip lights?

Yes. You can easily connect four flexible LED strips.

You will have to consider a few factors in your mind.

To connect four flexible LED strips, You need to add more power sources.

Adding power buses or power sources can add more power to the LED strips, and it may cause them to run easily.

It all depends upon the number of power sources as well as the power output.

You can easily connect four Flexible LED strips with connectors’ help, soldering the connection joints or cables.

Multiple flexible LED strips with different brands can also be connected easily, but they should have the same voltage.

6.  How Many Flexible LED Strip Lights Can I Connect?

Multiple LED strips can be connected.

It all depends upon the power source connected to LED strips.

Flexible LED strips can be connected based upon the quality of the power source.

If the quality is best and the power source is high, multiple Flexible LED strips can be connected.

You can also connect multiple power buses to connect more than one Flexible LED strip light.

Connecting LED stripsConnecting Flexible LED Strips

7.  How Do You Connect Two Flexible Light Strips Without Connectors?

This video can be helpful if you want to know how can easily connect Two Flexible Light Strips without using connectors :



8.  How Flexible Are “Flexible LED Strip Lights”?

Flexible LED strip lights are flexible to the extent that these can be easily bent, cut and designed to whatever shape you want.

These can be bent vertically up to 90 degrees easily.

This can allow you to provide light at those places where you think it is impossible.

You can cut Flexible LED strip lights.

It allows you to convert it to your demanded shape.

The given video can give you a better understanding of the flexibility of Flexible LED Strip Lights.



9.  Can You Bend Flexible Light Strip Around Corners?

You can bend Flexible Light strips around corners and “cannot” at the same time.

You can bend non-waterproof and standard LED strip tape around the corners easily as long as you bend them at the cut line position.

On the other hand, for trickier angles, You will cut the LED strip lights and solder a wire between separate lengths to carry the power supply.

Waterproof LED strips are not capable of bending.

It is because there is silicon coating over them to prevent them from water. Silicon coating is not that flexible to be bent.

Bending Flexible LED stripsBending RGB Flexible LED strips.

10.   Can I Cut The Bendable LED Strip?

Bendable LED strips are a versatile choice for any task lighting application for any kind of purpose.

This is one of Bendable LED strips’ biggest advantages: they can be cut easily into custom lengths.

Bendale LED strips are flexible enough to be bent.

This flexibility allows them to be cut into whatever length you want for your lighting project application.

One of the main advantages of Bendable LED strip lights over rigid LED strip lights is that they can be cut easily into custom lengths.

11.   How Do You Connect The RGB Flexible LED Strip?

The RGB Flexible LED strip can be connected through simple tricks. It can be observed in the given video :



12.   How To Bend Your Flexible RGB LED Strip Lights Laterally?

This video can give you a better understanding of bending your Flexible RGB LED strip lights laterally :



13.   What Does SMD Mean For LED Lights?

SMD stands for the surface mounted diode.

SMD is considered a better technology for LED lights.

SMD LED lights are enveloped in an epoxy resin as well as are mounted on an aluminium substrate.

SMD is known for offering higher lumen output for lower energy consumption.

It allows for a better quality of lumen, even on the lowest energy consumption.

It is because their working principle is based upon the process that larger and fewer.

SMD LED lights are used to produce a great lumen output.

You should keep in mind that the brightest SMD LEDs are from the 5730 series.

14.   How To Bend Your Flexible LED Tapes Laterally With Clip-On Connectors

The bending capability of Flexible LED tapes is what makes them too unique.

Bending of Flexible LED tapes can be performed through various techniques, but one of the most performed techniques is connecting them through Clip-On connectors.

Flexible LED tapes can be bent laterally with Clip-On connectors. It can be seen in detail in the given video below :



15.   How Do You Connect Two SMD LED Flexible Strips To One Power Source?

Two Flexible LED strips can be connected to one power source depending upon the power source’s capacity.

But the most important thing is even if you have a better power source, you will need something to connect two Flexible LED strips to one power source.

You will require a Hippo buckle connector.

You will simply install one end of your flexible LED strip to your hippo buckle connector to connect two SMD LED flexible strips to one power source.

The role of “buckle” is to keep these strips in one fixed place.

The hippo buckle connector and the power capacity of your power source are the main things to connect two flexible LED strips.

Connecting Flexible LED strips to One Power SourceConnecting Multiple LED strips to one Power Source

16.   How To Select An LED Power Supply?

You can easily select an LED power supply.

This can be figured out by multiplying the total wattage by 1.2.

This will tell you how to select the power supply for your flexible LED strips.

Suppose you have four runs of flexible LED strips.

These are using 12 watts for each. Now when you multiply four by 12, you come to know that it becomes 48.

It shows that the system wattage should be around 48 watts.

Now you add the 20% suggested cushion on with 48 x 1.2 = 57.6 Watts.

A 60-Watt (or higher) power supply will be enough for this project.

17.   How To Power SMD LED Flexible Strips?

Watch this video for further guidance about how to power your flexible LED strips :



18.   How Much Power Do You Need For A Flexible LED Strip?

The power that you will need for your flexible LED strip depends on the criteria that your flexible LED strip’s power should be 20% less than the rated wattage of the power supply.

Suppose you bought a flexible LED strip that has the requirement of 80 watts of power to run, then the power supply that you need for this strip will be at least 96 watts.

It should be kept in mind that a good LED strip should provide four watts per foot or more.

Power Needed for Flexible LED stripsPower Needed for Flexible LED Strips

19.   Can Flexible LED Strips Catch On Fire?

Flexible LED strips can or cannot catch fire depending upon so many factors.

If the quality of flexible LED strips is good enough, there are very few chances that they will be burnt.

Chances of catching fire increase when you buy a low-quality product.

When you buy a flexible LED strip from a low-guaranteed manufacturer, it can cause them to catch fire.

Otherwise, if the quality is good, there are no chances of catching fire.

Normally, a good flexible LED strip can be turned on for hours without catching fire.

20.   Can I Use SMD-LED Flexible Strips Without a Controller?

In most cases, It is possible to use your SMD LED Flexible strip without a controller.

You just need to apply the correct DC and voltage to the strip.

It will be applied to each of the three legs possessed by the SMD LED Flexible strip.

You will not have any control over the whiteness.

It will be due to spectral emission, but this trick will work anyway.

21.   Can I Control Multiple RGB Flexible LED Strips With One Remote?

Yes. It is possible to control multiple RGB Flexible LED strips with only one remote. Remote is capable of controlling more than one receiver.

All you need to do is to match the code with the receiver. For this purpose, you will be following the steps :

  1. You need to Plug in the multiple RGB Flexible LED strips with the receiver and the given power supply with a remote.
  2. After that, you will be holding the “on” button for five seconds; it will result in a flash of RGB Flexible LED strips.

It shows that the remote has successfully started working with the receiver.

You will be repeating this step to match it with multiple receivers.

This way, you can see that multiple RGB Flexible LED strips can be controlled through one remote.

22.   How Bright Should My Flexible LED Strip Light Be?

Depending upon the purpose of use, the lumen of your Flexible LED strip light will be varied.

For some events, you want more lumen, while for others, you want it to be less bright.

In the case of accent lighting, you will not require anything brighter than 200 Lumens per foot.

On the other hand, there may be certain other applications where you will probably require more light.

Again, It only depends on your preference for using your Flexible LED strip light.

23.   How Do I Install My Flexible Light Strip?

This video can be better guidance towards installing your flexible light strip :



24.   Which Strip Light Colour Is For Me?

Flexible LED light strips have various colours.

Each colour has its properties.

You can buy according to the properties of the colour.

For example, blue can be a healing colour.

It can also be used to increase the rate of blood flow.

Skin can also be sensitive to blue colour.

It can lead to removing pain from your body and promote healing.

On the other hand, green is a calming colour.

It conveys hope, healing and soothing.

The green colour is considered as most sensitive and visible to the human eye.

The given video can show how many colours flexible light strips possess :

Color of Flexible LED stripsColours for Flexible LED Strips

25.   How Much Will A Flexible Light Strip Cost?

The cost of a flexible light strip varies depending upon the length or colour you will choose for your flexible light strip.

It will vary between a range of $20 to $50.

For example, the cost of a basic stair nosing profile runs between $7 a foot and over $20 afoot.

It will all depend upon the size, manufacturer, and shape of the flexible light strip.

When you buy a product from a good manufacturer, It will cost high compared to the product from a bad manufacturer.

When you buy a lengthy flexible light strip, its cost will be higher than a short length strip.

26.   How To Connect A Flexible Light Strip?

You can watch this video for better guidance about connecting Flexible light strip:



27.   What Transformer Do I Need For The Flexible Light Strip?

Choosing a transformer for your flexible light strip depends upon a few factors.

These factors can be the power needed by a flexible light strip and the length of a flexible light strip.

The longer the length, the more will be the power supply.

Given video can tell you how you should choose a transformer for your flexible light strip.

Transformer of Flexible LED stripsTransformer for Flexible LED Strips

28.   Can I Leave A Bendable LED Strip On All Night?

Yes. You can leave your bendable LED strip on all night.

Bendable LED strips are considered ideal for being turned on all night.

This is because they have low power usage and low heat output.

Bendable light strips are best for using as background light and night light.

It also depends upon the quality of LED light strips.

If you buy bendable light strips from a good manufacturer, they can be truly long-lasting. Such bendable light strips can be turned on overnight.

29.   Can A Bendable LED Strip Give You Cancer?

No. There has never reported such a case that LED lights have caused any kind of cancer in anyone.

However, According to new research, it has been found that blue light emitted by bendable LED strips can cause cancer.

These can cause prostate and breast cancer.

Both of these cancers are hormone-related.

On the other hand, it has been observed that bendable led strips are very safe to use because they don’t create UV rays like so many other resources.

30.   How Many Amps Do I Need For The RGB Flexible LED Strip?

RGB Flexible LED strip’s current in amps can be found depending upon the LED strip’s length.

For example, if you have an RGB Flexible LED strip of length one meter, you need to multiply 60mA by 10, As there are ten segments per meter in a 30/LED per meter strip. You will get the result as 0.6 Amperes per meter.

If you have a 60/LED per meter strip, you will be multiplying 60mA by 20, and you will get the result as 1.2 Amperes per meter.

All you need to know is the number of LEDs per meter of the strip.

Once you know the number, you can easily find out the amps you will need for your RGB Flexible LED strip.

31.   How Do You Stick Flexible RGB LED Strip Lights To TV?

Flexible RGB LED strip lights can be used for various purposes.

RGB flexible LED strip lights can be stuck to the TV due to their flexibility and multiple uses. For knowing how this can be done easily, you can watch the given video :

Flexible LED strips TV installationFlexible LED Strips TV installation

32.   How Long flexible RGB LED Strip Lights To Stay On?

Flexible RGB LED strip lights are found to be safer and reliable than any other lighting products.

These lights don’t produce harmful waves like UV rays.

These lights can work on a low power supply. RGB LED strip lights don’t produce too much heat output.

RGB LED strip lights are considered ideal for staying on for a long period due to these flexible reasons.

You can turn them on overnight or 24 hours.

You should make sure that the quality of Long flexible RGB LED strip lights are good.

You should buy them from a good manufacturer otherwise they can catch fire.

33.   What Flexible RGB LED Strip Lights Are The Best?

Some various companies and manufacturers are selling the best flexible RGB LED strip lights.

A few of them are named as under :

      1. Govee Alexa Led Strip Lights Music Sync
      2. LED Strip Lights, L8star Colour Changing Rope Lights
      3. L8star LED Colour Changing Rope 32.8ft
      4. MINGER LED Strip Lights
      5. DAY BETTER Led Strip Lights 32.8ft
      6. MINGER RGBIC LED Strip Light with App Control
      7. PANGTON VILLA USB LED TV Backlight Kit
      8. Tenmiro Ultra Long RGB 5050 Color Changing LED Light Strips Kit
      9. Nexillumi LED Strip Lights
      10. Phopollo LED Strip Lights
      11. RaThun Led Strip Lights Kit
      12. BIHRTC LED Strip Lights
      13. DAY BETTER Led Strip Lights
      14. LED Strip Lights 32.8 ft, RGB 2835 LEDs
      15. Govee Smart WiFi LED Strip Lights Works with Alexa, Google Home.

34.   What Wire Do You Use For SMD-LED Flexible Strips?

Wire of SMD-LED flexible strips can be chosen according to the colour and length of the strips.

If your SMD-LED Flexible strips possess a single colour, then you must be needing a two-conductor wire.

On the other hand, if your SMD-LED flexible strips are an RGB strip, you must need a four conductors wire.

35.   How Do You Connect Flexible LED Strip Lights To Mains?

Connecting flexible LED strip lights to mains can be done easily through few steps. This installation process has been explained step by step in the given video :



36.    Where Should A Flexible LED Strip Be Placed In A Room?

Flexible LED strip can be placed and positioned anywhere you desire.

If you want to fit your Flexible LED horizontally, It will be better to stick the LED behind the drop ceiling’s lip.

It will help you to hide light-dots that are shining a vertical surface behind.

Adding your Flexible LED light strip anywhere in your room can enhance the appearance of your room’s space.

You can position your Flexible LED strip near cupboards and drawers.

It makes them more beautiful and easy to work with.

These strips can also be positioned on your walls and ceilings.

37.   How Do You Connect Flexible LED Strip Light To A 12V Battery?

You can easily connect your Flexible LED strip light to a 12V battery.

You have to go through few steps to achieve the strip’s connection to a 12 volts battery.

First, make sure that 12-volt output is selected by turning on the power button on your battery.

After that, you need to plug in one end of the DC cable into your battery’s DC output option.

You need to plug the other end of the strip into a barrel jack at the end of the strip. In this way, you can easily connect your Flexible LED strip lights to a 12 volts battery.

Flexible LED strips 12VFlexible LED Strip 12V

38.   Can I Power A 12V Flexible LED Strip Light With USB?

12V Flexible LED strip light can be powered through USB, but it needs few more Requirements.

The USB ports supply consists of 5 volts.

On the other hand, a 12 volts Flexible LED strip light requires at least 9 volts.

You need to consider few factors that connect USD to a 12V Flexible LED strip light; you need to buy a step-up DC-to-DC boost transformer circuit that allows you to step up from 1.5 volts to 24 volts or 32 volts.

In this way, you can boost 5 volts of USB to 12 volts and then you can connect your Flexible LED strip lights to it.

39.   Factors To Consider When Clipping and Soldering a Flexible Light Strip?

There are few factors that you need to consider when you are clipping or soldering your Flexible light strip.

  1. You should cut the LED wires from a copper connection. This is essential to avoid damage in tapes of LED.
  2. You should expose LED tapes and carefully remove the plastic casing, which are right next to the copper connections. This process will not be required when you will connect using a hippo connector.
  3. Ensure that you match the right wires on each side of your Flexible LED strip.
  4. You should use a heat shrink cover to protect connections.

40.   What is the Difference Between Flexible LED Strip Light And Led Rigid Strip Light?

The main difference between a flexible LED strip and a rigid LED strip is that flexible LED strips are easy to bend and easily used in rough places.

On the other hand, rigid LED strips can not be bent easily. Rigid LED strips can not be used in rough places.

Flexible LED strips are assembled with an FPC circuit board.

On the other hand, rigid LED strips are assembled with a PCB hardboard.

Rigid LED strips are capable of fixing very easily as compared to flexible LED strips. Moreover, these can be installed and processed easily.

41.   How Many Lumens Per LED Chip Do You Use For Your Flexible Strip Lights?

For a flexible light strip, lumens provided depends upon the Quality of the flexible LED strip.

If the Quality is high, then the strip can easily provide 450 lumens per foot.

It can be 1500 lumens per meter.

Moreover, you can determine the brightness of flexible LED strip lights by the light efficiency of your LED emitter, power consumption and the number of LEDs per foot.

42.   How To Choose The Right Flexible LED Strip?

You should keep in mind eight points while buying or choosing the right Flexible LED strip.

These eight points are explained in detail in the given video :











Send Your Inquiry Today
